工作場所空氣中鄰苯二甲酸酐測定填充柱
工作場所空氣中鄰苯二甲酸酐測定填充柱 詳細信息：

應用：GBZ/T 300.118-2017 工作場所空氣有毒物質測定 第118部分：乙酸酐、馬來酸酐 和鄰苯二甲酸酐
GBZ/T 160.60-2004 工作場所空氣有毒物質測定 酸酐類化合物

浩瀚色譜（山東）應用技術開發有限公司研發空氣中鄰苯二甲酸酐用玻璃纖維濾紙采集,隨即放入預先裝有2 ml丙酮的樣品瓶中,蓋塞,搖勻后用聚丁二酸乙醇酯:磷酸:101 硅烷化白色擔體柱氣相色譜(FID)測定。鄰苯二甲酸酐濃度在0~200μg/ml范圍內線性關系良好,線性方程y=8.9+12.6x(r=0.999 9。檢出限為0.39μg/ml,若采集30 L空氣樣品,則低檢出濃度分別為0.026 mg/m3,平均加標回收率99.7%~101.4%,相對標準偏差在1.2%~3.7%。本方法適用于工作場所空氣中鄰苯二甲酸酐濃度的測定。

工作場所空氣中鄰苯二甲酸酐測定填充柱  測試譜圖：


Packed column for determination of phthalic anhydride in workplace air
Packed column for the determination of phthalic anhydride in workplace air Details:

Chromatographic column: 2m×4mm, polysuccinate:phosphoric acid:101 Silanized white support = 5:1.5:100;
b) Column temperature: 175℃;
c) Temperature of gasification chamber: 220℃;
d) Test room temperature: 220℃;
e) Carrier gas (nitrogen) flow: 25mL/min.
Application: GBZ/T 300.118-2017 Determination of Toxic Substances in Workplace Air Part 118: Acetic Anhydride, Maleic Anhydride and Phthalic Anhydride
GBZ/T 160.60-2004 Determination of Toxic Substances in Workplace Air - Acid Anhydrides

Haohan Chromatography (Shandong) Application Technology Development Co., Ltd. developed phthalic anhydride in the air to collect glass fiber filter paper, then put it into a sample bottle pre-filled with 2 ml of acetone, cap it, shake it well, and use polysuccinic acid ethanol Esters: Phosphoric acid: 101 Determination by gas chromatography (FID) on a silanized white support column. The phthalic anhydride concentration has a good linear relationship in the range of 0~200μg/ml, the linear equation y=8.9+12.6x(r=0.999 9. The detection limit is 0.39μg/ml, and if 30 L air samples are collected, the lowest The detected concentrations were 0.026 mg/m3, the average recovery rates were 99.7%-101.4%, and the relative standard deviations were 1.2%-3.7%. This method is suitable for the determination of phthalic anhydride concentration in workplace air.

Packed column for determination of phthalic anhydride in workplace air Test spectrum:
