名稱：填充柱

固定液：2.5%鄰苯甲酸二壬酯（DNP）+2.5%有機皂土-34（Bentone-34）

擔體：Chromosorb G.DMCS ，60-80目

規(guī)格：2m*1/8,2m*3mm（外徑），2m*4mm（外徑）

型號：2.5%DNP+2.5%Bentone-34/Chromosorb G.DMCS

應用：HJ/T 66-2001 大氣固定污染源 氯苯類化合物的測定 氣相色譜法

HJ/T 66-2001 Air Stationary Pollution Sources Determination of Chlorobenzene Compounds
HJ/T 66-2001 Air Stationary Pollution Sources Determination of Chlorobenzene Compounds Details:

Name: Packed Column

Fixative: 2.5% dinonyl phthalate (DNP) + 2.5% organic bentonite-34 (Bentone-34)

Carrier: Chromosorb G.DMCS, 60-80 mesh

Specifications: 2m*1/8, 2m*3mm (outer diameter), 2m*4mm (outer diameter)

Model: 2.5%DNP+2.5%Bentone-34/Chromosorb G.DMCS

Application: HJ/T 66-2001 Air Stationary Pollution Sources Determination of Chlorobenzene Compounds Gas Chromatography

HJ/T 66-2001 Air Stationary Pollution Sources-Determination of Chlorobenzene Compounds-Gas Chromatography
1 Scope of application

1.1 This standard is applicable to the determination of chlorobenzene compounds from organized and unorganized emissions from stationary sources of atmospheric pollution.

1.2 When the sampling volume is 30L, the desorption volume is 3ml, and the chromatographic injection is 1μL, the detection limit of the method is shown in Table 1.

                             Table 1 Detection limit of the method/(mg/m3)


      The detection limits of the methods vary when the instruments used are different.

2 Reference standards

The following standards contain provisions which, through reference in this standard, constitute official provisions of this standard. At the time of publication, the editions indicated were valid. All standards are subject to revision and parties using this standard should explore the possibility of using the latest edition of the following standards.

      GB/T 16157-1996 Determination of particulate matter in exhaust gas from stationary pollution sources and sampling methods for gaseous pollutants

      GB 16297-1996 Comprehensive emission standard of air pollutants

3 Definitions

Chlorobenzenes: A general term for a series of chlorine-substituted isomers of benzene. In this standard, it refers to the sum of the determination results of chlorobenzene, 1,4-dichlorobenzene and 1,2,4-trichlorobenzene.

4 Reagents and Materials

      Unless otherwise specified, this standard uses analytical reagents and distilled water or water of equivalent purity that meet national standards.

4.1 Carrier and auxiliary gases

a Carrier gas: nitrogen, with a purity of 99.9V, purified with a 5A molecular sieve purification tube.

b Combustion gas: hydrogen, purity 99.9%, purified with 5A molecular sieve purification tube.

c Gas-supporting gas: air, purify with 5A molecular sieve purification tube.
